Simrad NSX® 3012, no transducer
Simrad NSX® 3012, no transducer
SKU:000-15223-001
✅ Authorized dealer and marine specialist
✅ 2 year manufacturer warranty
✅ Not sure what fits? Contact us for advice
Couldn't load pickup availability
Simrad NSX 3012 without transducer
Modern multitouch chartplotter from the NSX series with NEON operating system.
The NSX 12 is a multifunction display from Simrad's latest NSX series, built on the NEON operating system. The device is entirely touch-first designed, featuring a fluid interface that operates like a modern tablet. This model comes without a transducer and is ideal for installations where you later want to connect your own transducer or sonar module.
With built-in Wi-Fi and Bluetooth, the device directly pairs with a smartphone or tablet for over-the-air updates, map downloads, and route sharing.
Why choose the NSX 12?
- NEON OS with touch-first interface: intuitive operation with swiping and pinching.
- Bright multitouch screen: high resolution and good readability in sunlight.
- Wi-Fi and Bluetooth standard: direct connection with smartphone, over-the-air updates.
- Full integration: NMEA 2000, Ethernet, and compatible with HALO radar, S3100H sonar, and NAC autopilots.
- Cloud synchronization: waypoints and routes via the Simrad app.
Who is this product made for?
The NSX 12 is intended for boaters who want a modern multifunction display with the latest Simrad technology. Suitable for recreational motorboats, sailboats, and sport fishing boats where a 12-inch screen fits well.
What does it offer you?
- Future-proof technology: regular updates and expansions via NEON OS.
- Fast operation: immediate touch response without delay.
- Mobile connectivity: direct app integration with smartphone or tablet.
- Compact installation: all-in-one device with built-in GPS and Wi-Fi.
- Expandable system: expand with radar, sonar, and autopilot without replacing the main unit.
Technical specifications
| Screen size | 12 inch multi-touch |
|---|---|
| Operating system | NEON OS |
| Control | Touchscreen |
| Built-in GPS | Yes, multi-constellation GNSS |
| Network | NMEA 2000, Ethernet, Wi-Fi, Bluetooth |
| Sonar | Prepared for external transducer or sonar module |
| Power supply | 12 V DC |
| Water resistance | IPX7 |
| Chart system | C-MAP DISCOVER included, support for C-MAP and Navionics |
| Mounting | Bracket mount or panel mount |
Additional features
- Auto Routing via C-MAP: automatic route planning based on waterway and depth.
- Over-the-air updates: wirelessly update firmware and charts.
- HALO radar support: compatible with Simrad HALO radomes and open array radars.
- Autopilot integration: control of compatible Simrad autopilots.
- Multi-screen layout: flexible layout with multiple panels on one screen.
- Cloud linking: synchronize waypoints and routes via the Simrad app.
- S3100H sonar support: networkable sonar connectable via Ethernet.
